Located in Mumbai, India, PTFE Lined Pipe is a renowned manufacturer and supplier of quality Teflon Lined Fittings ideal for dealing with corrosive and high-temperature fluids in critical industrial processes. We are experts in FEP, PFA, and PTFE lined products and provide sure-shot solutions for demanding environments. Our Teflon Lined Fittings are designed to last, have superior chemical resistance, and repeatable performance. With its smooth inner lining, sturdy construction, and reliable sealing, they facilitate effective fluid flow and can be tailored to suit individual system and process requirements.
Teflon Lined Fittings are specially manufactured pipe fittings having an internal PTFE (Teflon) lining which is a strongly resistant and inert coating. Teflon-lined fittings are specifically designed for carrying aggressive chemicals, corrosive chemicals and high temperature fluids without having any possibility of damage. Teflon lined delivers a frictionless, non-stick surface that guarantees leak-tight performance, minimizes the risk of contamination and maximizes service life of piping system. Employed extensively in chemical processing, pharmaceuticals, food and beverage and water treatment, Teflon Lined Fittings are instrumental in sustaining purity, optimizing flow efficiency, and providing safe operation under hostile conditions.
Size : 25 NB to 300 NB
Flanges Used : ASTM A 105/IS 2062/SS 304/SS 316
Hydro Test : at 29.8 Kg/cm2
Spark Test : 15 KVA
Outer body : ASTM A 234 Gr WPB SCH-40/SS 304/SS 316
Lining : Teflon
Vivek PTFE Lined Pipe is a leading supplier of Teflon Lined Pipe Fittings in Mumbai, India, offering high-quality, corrosion-resistant solutions ideal for chemical, pharmaceutical, and industrial applications.
|
NB
|
ID
|
RF
|
OD
|
PCD
|
No.Of Holes x Dia Of Holes
|
Lining Thickness Standard
|
Lining Thickness Full Vacuum
|
Length Max.
|
| 15 | 10.80 | 34.90 | 88.9 | 60.3 | 4×15.9 | 3.0 | 3.1 | 3000 |
| 20 | 16.00 | 42.70 | 98.4 | 69.8 | 4X15.9 | 3.0 | 3.1 | 3000 |
| 25 | 20.15 | 50.80 | 108.0 | 79.4 | 4X15.9 | 3.2 | 3.5 | 3000 |
| 40 | 33.90 | 73.00 | 127.0 | 98.4 | 4X15.9 | 3.2 | 3.5 | 3000 |
| 50 | 45.50 | 92.10 | 152.4 | 120.7 | 4X19 | 3.5 | 4.6 | 3000 |
| 65 | 55.68 | 104.80 | 177.8 | 139.7 | 4×19 | 3.5 | 4.8 | 3000 |
| 80 | 70.90 | 127.00 | 190.5 | 152.4 | 4X19 | 3.5 | 5.0 | 3000 |
| 100 | 94.30 | 157.20 | 228.6 | 190.5 | 8X19 | 4.0 | 5.8 | 3000 |
| 150 | 114.10 | 215.90 | 279.5 | 241.3 | 8X22.2 | 5.0 | 6.8 | 3000 |
| 200 | 195.10 | 269.90 | 342.9 | 298.5 | 8X22.2 | 5.0 | 7.9 | 2000 |
| 250 | 247.40 | 323.90 | 406.4 | 362.0 | 12X25.4 | 5.0 | 8.8 | 2000 |
| 300 | 297.00 | 381.00 | 482.6 | 431.8 | 12X25.4 | 5.0 | 9.0 | **** |
Withstands aggressive acids, alkalis, and solvents without degrading.
Performs reliably in elevated temperature environments up to 260°C.
Ensures tight, secure connections for safe and efficient operation.
Offers durability and reduces maintenance costs in harsh industrial settings.
Teflon Lined Fittings are widely used in the chemical, pharmaceutical, and food industries where corrosion resistance and contamination-free fluid handling are essential.
Standard sizes range from 25mm to 300mm, with custom sizing available to meet specific application needs.
Yes, these fittings can generally endure temperatures up to 260°C, depending on the process conditions and pressure requirements.
Yes, they offer excellent chemical resistance, making them suitable for handling aggressive acids, alkalis, and solvents.
Yes, the Teflon lining ensures a secure, leak-proof seal, helping to minimize maintenance needs and improve safety in industrial systems.
We are the leading Manufacturer and Supplier of Vivek PTFE Lined Pipe, Fittings, Flanges, Spool and Valves in Mumbai, India.
