We at PTFE Lined Pipe produce high-performance PTFE Lined Reducers designed to withstand harsh industrial environments. With our base in Mumbai, India, we are a reliable name for producing long-lasting and reliable PTFE, FEP and PFA lined products. Our PTFE Lined Reducers are specifically designed to deal with aggressive chemicals and high temperatures while providing long-lasting performance. With robust construction, great chemical resistance and a smooth bore for smooth flow, they provide an ideal transition between various pipe sizes. And, they can be made to fit a broad spectrum of industry requirements and process demands.
A PTFE Lined Reducer is a special type of pipe fitting used to connect two pipes of different sizes while protecting against chemical corrosion. It has a strong steel body on the outside and a smooth PTFE lining on the inside, making it perfect for handling aggressive chemicals safely. PTFE lined reducers are widely used in industries like chemical processing, pharmaceuticals, and food production where durability and leak-proof performance are important.
Size : 25 NB to 300 NB
Outer body : ASTM A 395 Gr 60-40-18
Flange Connection : ANSI B 16.5
Face to Face : ANSI B 16.10
Spark Test : 15 KVA
Hydro Test : at 29.8 kg/cm2
FEP- Max Temp : 180° C
PP Max Temp : 100° C
PFA Max Temp : 200° C
Vivek PTFE Lined Pipe is a leading supplier of PTFE Lined Reducer in Mumbai, India, offering high-quality, corrosion-resistant solutions ideal for chemical, pharmaceutical, and industrial applications.
| NB | L | FLG. | RF | PCD | App. | App. | LINER THK | N x M | WEIGHTS | |
|---|---|---|---|---|---|---|---|---|---|---|
| O / D | O / D | T1 | T1 | Vaccume (T) | Non Vacc (T) | (kg/piece) | ||||
| 1/2″ | —- | 89 | 35.1 | 60.5 | 14.2 | 24.2 | 3.0 | 3.0 | 4 x 1/2″ | 4 |
| 3/4″ | —- | 98 | 42.9 | 69.9 | 15.7 | 27.7 | 3.0 | 3.0 | 4 x 1/2″ | 3.5 |
| 1″ | 89 | 108 | 50.8 | 79.2 | 17.2 | 29.2 | 4.0 | 3.0 | 4 x 1/2″ | 5.5 |
| 1 1/4″ | 95 | 118 | 63.5 | 88.9 | 18.7 | 30.2 | 4.0 | 3.0 | 4 x 1/2″ | 7.7 |
| 1 1/2″ | 102 | 127 | 73.2 | 98.6 | 20.5 | 32.5 | 4.0 | 3.0 | 4 x 1/2″ | 8.7 |
| 2″ | 114 | 152 | 91.9 | 120.7 | 22.1 | 37.1 | 4.0 | 3.0 | 4 x 1/2″ | 14.0 |
| 2 1/2″ | 127 | 178 | 104.6 | 139.7 | 25.4 | 40.4 | 4.0 | 3.0 | 4 x 5/8″ | 20.6 |
| 3″ | 140 | 191 | 127.0 | 152.4 | 27.9 | 42.9 | 4.0 | 3.0 | 4 x 5/8″ | 24.8 |
| 4″ | 165 | 229 | 157.2 | 190.5 | 28.9 | 43.9 | 4.5 | 3.0 | 8 x 5/8″ | 39.1 |
| 5″ | 190 | 254 | 185.7 | 215.9 | 28.9 | 43.9 | 6.0 | 5.0 | 8 x 3/4″ | 68.8 |
| 6″ | 203 | 279 | 215.9 | 241.3 | 30.4 | 45.4 | 6.0 | 5.0 | 8 x 3/4″ | 79.5 |
| 8″ | 229 | 343 | 269.7 | 298.5 | 33.4 | 48.4 | 6.0 | 5.0 | 8 x 3/4″ | 99.0 |
| 10″ | 280 | 406 | 323.9 | 362.0 | 35.7 | 50.7 | 7.5 | 5.0 | 12 x 7/8″ | 160.0 |
| 12″ | 305 | 483 | 381.0 | 431.8 | 37.8 | 52.8 | 7.5 | 5.0 | 12 x 7/8″ | 280.0 |
Withstands harsh acids and solvents.
Prevents fluid leakage at joints.
Suitable for extreme process heat.
Tailored to fit system specifications.
Yes, custom sizes are available for PTFE, FEP, and PFA lined reducers to meet specific project requirements. Tailored dimensions and designs can be provided based on application needs.
Yes, these liners are designed to withstand high temperatures, making them ideal for applications involving hot, corrosive fluids.
Both concentric and eccentric reducers can be lined to ensure smooth flow transitions while protecting against corrosion.
Yes, these lined reducers are often designed to handle vacuum conditions without compromising their structural or chemical resistance.
Yes, they are highly versatile and effective for safely transporting both aggressive liquids and gases.
