PTFE Lined Pipe is a prominent manufacturer and exporter of Ball Valves with PTFE, FEP and PFA lining. Our SS 304 FEP Lined Ball Valves are fitted with anti-static devices that ensure safety through the prevention of electrostatic discharge. In the meantime, our SS 316 PFA Lined Ball Valves are made for low-torque and smooth operation, easy to handle and efficient. These valves also have an anti-blowout stem assembly, which prevents stem blowouts even without a top gear assembly. Both valves are coated with high-quality PFA and FEP, which gives them better durability and resistance.
A PTFE-lined ball valve is a type of valve with a ball inside that controls the flow of fluids. The ball is lined with PTFE (polytetrafluoroethylene), a substance renowned for its high resistance to corrosion, chemicals, and heat. This makes PTFE-lined ball valves perfect for processing aggressive fluids in industries such as chemicals, pharmaceuticals, and food processing. They are durable, smooth, and leak-proof.
Size: 25 NB TO 80 NB.
Flange Connection: ANSI B 16.5
Face to Face: ANSI B 16.10
Spark Test: 15 KVA
Hydro Body Test: 15 kg/cm²
Hydro Seat Test: 10 kg/cm²
Leak Test: as per API 598
Temperature: FEP – Max 180°C, PFA – Max 200°C
PTFE Lined Pipe is a leading supplier of PTFE Lined Ball Valve in Mumbai, India, offering high-quality, corrosion-resistant solutions ideal for chemical, pharmaceutical, and industrial applications.
|
SIZE |
L |
G |
H |
WEIGHT |
|
15 |
108 |
134 |
85 |
2.15 Kg |
|
20 |
117 |
133 |
85 |
3.10 Kg |
|
25 |
127 |
158 |
95 |
3.75 Kg |
|
40 |
165 |
228 |
120 |
6.75 Kg |
|
50 |
178 |
228 |
135 |
9.75 Kg |
|
80 |
203 |
325 |
165 |
19.50 Kg |
|
100 |
229 |
377 |
180 |
31.00 Kg |
|
150 |
267 |
548 |
250 |
56.00 Kg |
Perfect for use in aggressive chemical environments.
Promotes smooth flow and minimizes material buildup.
Handles extreme conditions—up to 260°C and high pressure levels.
Delivers comparable performance at a significantly lower cost.
A PTFE-lined ball valve features a corrosion-resistant PTFE coating, making it ideal for flow control in corrosive environments such as chemical plants, pharmaceuticals, and wastewater treatment systems.
PTFE-lined ball valves can typically handle temperatures up to 260°C and moderate to high pressures, ensuring reliable performance in challenging applications with aggressive chemicals or high thermal conditions.
Yes, PTFE-lined ball valves are designed for easy maintenance. The PTFE lining helps prevent the buildup of corrosive materials, reducing the need for frequent repairs and allowing for longer operational life compared to unlined valves.
Yes, PTFE-lined ball valves can handle temperatures up to 260°C, making them suitable for high-temperature applications, especially in chemical and pharmaceutical industries where precise temperature control is critical.
PTFE-lined ball valves offer a cost-effective solution compared to exotic alloy valves. They provide excellent chemical resistance at a lower cost, making them a popular choice for industries where corrosion resistance is critical but budget constraints exist.
